Grayhill
95C04A5T
Switch Tactile N.O. SPST Rectangular Button PC Pins 0.05A 12VDC 3.14N Thru-Hole Tube
MountingThrough Hole
Quick Jump:
Technical Specifications
Grayhill 95C04A5T technical specifications.
General
Actuator Material
Nylon, Polyamide
Contact Material
Stainless Steel
Contact Plating
Silver
Illumination Type
Non-Illuminated
Max Operating Temperature
70°C
Min Operating Temperature
-25°C
Max Voltage Rating (DC)
12V
Mechanical Life
50000Cycles
Mount
Through Hole
Operating Force
320gf
Packaging
Rail/Tube
RoHS Compliant
Yes
Series
95C
Switch Function
Off-Mom
Switch Travel
0.25mm
Termination
PC Pin
Throw Configuration
SPST
Compliance
RoHS
Compliant
Datasheet
Grayhill 95C04A5T Datasheet
Download the complete datasheet for Grayhill 95C04A5T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
