SPST DIP switch featuring a standard slide actuator, 2 positions, and 2 switches. Surface mountable with gull wing termination and a 1.27mm terminal pitch. Offers a 25mA current rating at 24VDC and a mechanical life of 1000 cycles. Constructed with nylon and thermoplastic materials, it operates within a -40°C to 85°C temperature range.
Capacitance5pF
Current Rating25mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Grayhill 97C02T technical specifications.
General
Actuator Length
0mm
Actuator Material
Nylon, Thermoplastic
Actuator Type
Slide (Standard)
Body Material
Nylon, Polyamide
Capacitance
5pF
Contact Material
Copper Alloy, Brass
Contact Plating
Gold, Nickel
Current Rating
25mA
Height
1.27mm
Lead/Base Style
Gull Wing
Material
Nylon, Thermoplastic
Max Current Rating
25mA
Max Operating Temperature
85°C
Mechanical Life
1000Cycles
Min Operating Temperature
-40°C
Max Voltage Rating (DC)
24V
Mount
Surface Mount
Number of Poles
1
Number of Positions
2
Number of Switches
2
Orientation
Straight
Packaging
Rail/Tube
Pitch
0.05inch
Radiation Hardening
No
RoHS Compliant
Yes
Series
97
Terminal Pitch
1.27mm
Termination
Gull Wing
Throw Configuration
SPST
DC Rated Voltage
24V
Washable
No
Width
4.5mm
Compliance
RoHS
Compliant
