This is a rotary switch with a current rating of 20A and a voltage rating of 600V AC. It is designed for chassis mount and features a SPDT throw configuration. The switch operates at a DC rated voltage of 115V and has an operating force of 13.34N. It is compliant with RoHS regulations and is packaged in bulk.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell 51ML1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Rotary |
| Current Rating | 20A |
| Depth | 81.03mm |
| Height | 189.55mm |
| Length | 53.85mm |
| Max Current Rating | 20A |
| Mount | Chassis Mount, Screw |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Operating Force | 13.34N |
| Orientation | Right Angle |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | ML |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 600V |
| DC Rated Voltage | 115V |
| Width | 2.12inch |
| RoHS | Compliant |
Download the complete datasheet for Honeywell 51ML1 to view detailed technical specifications.
