Snap acting/limit switch featuring SPDT, momentary contact with a 0.51mm travel. This general-purpose switch offers a 1A contact current rating with gold contact material and a 15A maximum current rating. It boasts a 125V AC and 125V DC voltage rating, with screw terminals for chassis or panel mounting. Designed for durability, it has an electrical life of 100,000 cycles and a mechanical life of 20,000,000 cycles, operating within a temperature range of -55°C to 85°C.
Package125
Current Rating1A
MountingChassis Mount, Panel, Screw
Quick Jump:
Technical Specifications
Honeywell BZ-2R72-A2 technical specifications.
General
Actuator Type
PLUNGER
Approvals
UL, CSA
Package/Case
125
Contact Current Rating
1A
Contact Material
Gold
Contact Type
Snap Action
Current Rating
1A
Depth
17.5mm
Electrical Life
100000Cycles
Lead Free
Lead Free
Length
49.3mm
Material
Plastic
Max Current Rating
15A
Max Operating Temperature
85°C
Mechanical Life
20000000Cycles
Min Operating Temperature
-55°C
Max Voltage Rating (AC)
125V
Mount
Chassis Mount, Panel, Screw
Operating Force
361N
Operating Position
1588mm
Orientation
Straight
Package Quantity
5
Packaging
Bulk
Reach SVHC Compliant
No
RoHS Compliant
Yes
Sealable
No (Without)
Series
BZ
Switch Function
On-Mom
Termination
Screw
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
125V
Weight
3401g
Width
1.94inch
Compliance
RoHS
Compliant
