SPDT snap acting switch with a steel roller lever actuator. Features a 15A contact current rating, silver contact material, and a 125VDC voltage rating. Operating temperature range from -55°C to 85°C, with a mechanical life of 20,000,000 cycles. Panel mountable with screw terminals, this switch offers a 0.04-inch differential travel and 216mm overtravel.
Current Rating15A
MountingChassis Mount, Screw
Quick Jump:
Technical Specifications
Honeywell BZ-2RW8299-A2 technical specifications.
General
Actuator Length
4822mm
Actuator Type
ROLLER LEVER
Contact Current Rating
15A
Contact Material
Silver
Current Rating
15A
Depth
17.45mm
Differential Travel
0.04inch
Height
24.1mm
Length
64.26mm
Material
Plastic
Max Current Rating
16A
Max Operating Temperature
85°C
Max Voltage Rating (AC)
480V
Max Voltage Rating (DC)
250V
Mechanical Life
20000000Cycles
Min Operating Temperature
-55°C
Mount
Chassis Mount, Screw
Operating Position
1.24inch
Orientation
Straight
Overtravel
216mm
Package Quantity
5
Packaging
Bulk
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sealable
No (Without)
Series
BZ
Switch Function
On-Mom
Termination
Screw
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
125V
Weight
345g
Width
49.3mm
Compliance
RoHS
Compliant
Datasheet
Honeywell BZ-2RW8299-A2 Datasheet
Download the complete datasheet for Honeywell BZ-2RW8299-A2 to view detailed technical specifications.
