Technical Specifications
Honeywell HOA0865-T55 technical specifications.
General
Collector Emitter Breakdown Voltage
30V
Collector Emitter Voltage (VCEO)
30V
Collector-emitter Voltage-Max
30V
Fall Time
15us
Forward Current
50mA
Height
10.8mm
Input Current
20mA
Max Collector Current
30mA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
100mW
Mount
Through Hole, Screw
Number of Channels
1
Number of Elements
1
Output Type
Phototransistor
Packaging
Bulk
Power Dissipation
100mW
Reach SVHC Compliant
No
Response Time
15us
Reverse Breakdown Voltage
3V
Reverse Voltage (DC)
3V
RoHS Compliant
No
Compliance
RoHS
Not Compliant
Datasheet
Honeywell HOA0865-T55 Datasheet
Download the complete datasheet for Honeywell HOA0865-T55 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
