Technical Specifications
Infineon BC817SUE6327 technical specifications.
General
Package/Case
SC
Collector Base Voltage (VCBO)
50V
Collector Emitter Breakdown Voltage
45V
Collector Emitter Saturation Voltage
400mV
Collector-emitter Voltage-Max
400mV
Emitter Base Voltage (VEBO)
5V
Height
1mm
Length
2.9mm
Max Breakdown Voltage
45V
Max Collector Current
500mA
Max Frequency
170MHz
Max Operating Temperature
150°C
Max Power Dissipation
1W
Mount
Surface Mount
Package Quantity
1
Packaging
Cut Tape
Reach SVHC Compliant
Yes
Transition Frequency
170MHz
Width
1.6mm
Compliance
RoHS
Compliant
Datasheet
Infineon BC817SUE6327 Datasheet
Download the complete datasheet for Infineon BC817SUE6327 to view detailed technical specifications.
