Technical Specifications
Infineon BCR116SH6327 technical specifications.
General
Package/Case
SOT-363-6
Collector Emitter Breakdown Voltage
50V
Collector Emitter Saturation Voltage
300mV
Collector-emitter Voltage-Max
300mV
Emitter Base Voltage (VEBO)
5V
Height
0.8mm
Length
2mm
Max Collector Current
100mA
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Power Dissipation
250mW
Mount
Surface Mount
Package Quantity
3000
Packaging
Tape and Reel
Transition Frequency
150MHz
Width
1.25mm
Compliance
RoHS
Compliant
Datasheet
Infineon BCR116SH6327 Datasheet
Download the complete datasheet for Infineon BCR116SH6327 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
