This 44-pin commercial temperature SRAM IC operates at a supply voltage of 3.3V, with a maximum supply voltage of 3.6V and a minimum supply voltage of 3V. The device has a maximum supply current of 0.17A and a standby current of 0.01A. The access time is maximally 12ns. It is available in a SOJ44 package and is a standard SRAM memory IC with 256K x 16 words of parallel access.
Quick Jump:
Technical Specifications
Integrated Device Technology 71V416L12YG8 technical specifications.
General
| Max Operating Temperature | 70 |
| Number of Terminals | 44 |
| Min Operating Temperature | 0 |
| Terminal Position | DUAL |
| JEDEC Package Code | R-PDSO-J44 |
| Pin Count | 44 |
| Number of Functions | 1 |
| Temperature Grade | COMMERCIAL |
| Supply Voltage-Nom (Vsup) | 3.3 |
| Supply Voltage-Max (Vsup) | 3.6 |
| Supply Voltage-Min (Vsup) | 3 |
| Supply Current-Max | 0.17 |
| Number of Words | 262144 |
| Number of Words Code | 256000 |
| Memory IC Type | STANDARD SRAM |
| Parallel/Serial | PARALLEL |
| Standby Current-Max | 0.01 |
| Access Time-Max | 12 |
| I/O Type | COMMON |
Compliance
| RoHS | Yes |
| Eccn Code | 3A991.B.2.A |
| Lead Free | Yes |
| HTS Code | 8542.32.00.41 |
| REACH | Compliant |
| Military Spec | False |
Datasheet
Integrated Device Technology 71V416L12YG8 Datasheet
Download the complete datasheet for Integrated Device Technology 71V416L12YG8 to view detailed technical specifications.
No datasheet is available for this part.
