Technical Specifications
Integrated Device Technology 71V65803S100BGG technical specifications.
General
Max Operating Temperature
70
Number of Terminals
119
Min Operating Temperature
0
Terminal Position
BOTTOM
JEDEC Package Code
R-PBGA-B119
Width
14
Length
22
Pin Count
119
Number of Functions
1
Temperature Grade
COMMERCIAL
Supply Voltage-Nom (Vsup)
3.3
Supply Voltage-Max (Vsup)
3.465
Supply Voltage-Min (Vsup)
3.135
Supply Current-Max
0.25
Number of Words
524288
Number of Words Code
512000
Memory IC Type
ZBT SRAM
Parallel/Serial
PARALLEL
Standby Current-Max
0.04
Access Time-Max
5
I/O Type
COMMON
Compliance
RoHS
Yes
Eccn Code
3A991.B.2.A
Lead Free
Yes
HTS Code
8542.32.00.41
REACH
Compliant
Military Spec
False
Datasheet
Integrated Device Technology 71V65803S100BGG Datasheet
Download the complete datasheet for Integrated Device Technology 71V65803S100BGG to view detailed technical specifications.
No datasheet is available for this part.
