Illuminated pushbutton switch featuring SPDT (Single Pole Double Throw) functionality with a 6A current rating and 120V AC / 28V DC voltage rating. This panel-mount switch utilizes silver contacts with silver plating and offers a straight, PC pin termination. The black nylon square button actuator has a length of 3.68mm, and the unit includes red LED illumination. Operating within a temperature range of -30°C to 65°C, this RoHS compliant component boasts an electrical life of 50,000 cycles.
Current Rating6A
MountingPanel, Snap in, Through Hole
Quick Jump:
Technical Specifications
ITT 8161J82CQE22 technical specifications.
General
Actuator Color
Black
Actuator Length
3.68mm
Actuator Material
Nylon
Actuator Type
Square, Button
Contact Material
Silver
Contact Plating
Silver
Current Rating
6A
Depth
15.62mm
Electrical Life
50000Cycles
Illumination Color
Red
Illumination Type
LED
Length
27.94mm
Max Current Rating
6A
Max Operating Temperature
65°C
Min Operating Temperature
-30°C
Max Voltage Rating (AC)
250V
Max Voltage Rating (DC)
28V
Mount
Panel, Snap in, Through Hole
Orientation
Straight
Package Quantity
1
Packaging
Bulk
RoHS Compliant
Yes
Series
8060
Switch Function
On-On
Termination
PC Pins
Throw Configuration
SPDT
Voltage Rating (AC)
120V
DC Rated Voltage
28V
Compliance
RoHS
Compliant
Datasheet
ITT 8161J82CQE22 Datasheet
Download the complete datasheet for ITT 8161J82CQE22 to view detailed technical specifications.
