4-position rotary switch with DP4T throw configuration, rated for 2.5A at 125V AC/DC. Features silver contacts with silver plating and a non-shorting contact style. Operates across a temperature range of -30°C to 85°C with an electrical life of 300,000 cycles. Includes a 38.1mm nylon and glass actuator and a straight, panel-mount orientation with solder termination.
MountingPanel
Quick Jump:
Technical Specifications
ITT A20415RNZQ technical specifications.
General
Actuator Length
38.1mm
Actuator Material
Nylon, Glass
Contact Material
Silver
Contact Plating
Silver
Contact Style
Non-Shorting
Depth
26.19mm
Electrical Life
300000Cycles
Index Angle
30°
Index Stops
Fixed
Length
26.19mm
Max Current Rating
2.5A
Max Operating Temperature
85°C
Min Operating Temperature
-30°C
Max Voltage Rating (AC)
125V
Max Voltage Rating (DC)
125V
Mount
Panel
Number of Decks
1
Number of Poles per Deck
2
Number of Positions
4
Orientation
Straight
Package Quantity
1
Packaging
Bulk
Radiation Hardening
No
RoHS Compliant
Yes
Series
A
Termination
Solder
Throw Configuration
DP4T
Voltage Rating (AC)
125V
DC Rated Voltage
125V
Compliance
RoHS
Compliant
Datasheet
ITT A20415RNZQ Datasheet
Download the complete datasheet for ITT A20415RNZQ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
