Technical Specifications
Ixys DSB10I45PM technical specifications.
General
| Average Rectified Current | 10A |
| Package/Case | TO-220-2 |
| Forward Current | 10A |
| Lead Free | Lead Free |
| Max Forward Surge Current (Ifsm) | 110A |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Repetitive Reverse Voltage (Vrrm) | 45V |
| Max Reverse Current | 7mA |
| Max Reverse Leakage Current | 7mA |
| Max Reverse Voltage (DC) | 45V |
| Max Surge Current | 112A |
| Mount | Through Hole |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Dissipation | 30W |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Ixys DSB10I45PM Datasheet
Download the complete datasheet for Ixys DSB10I45PM to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
