Package1206
Capacitance220nF
Voltage Rating16V
MountingSurface Mount
Quick Jump:
Technical Specifications
Johanson 160X18W224MV4E technical specifications.
General
Capacitance
220nF
Case Code (Imperial)
1206
Case Code (Metric)
3216
Package/Case
1206
Depth
1.6mm
Dielectric
X7R
Height
1.27mm
Length
3.15mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Package Quantity
3000
Packaging
Tape and Reel
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
X2Y®
Termination
SMD/SMT
Tolerance
20%
Voltage Rating
16V
DC Rated Voltage
16V
Width
1.6mm
Compliance
RoHS
Compliant
Datasheet
Johanson 160X18W224MV4E Datasheet
Download the complete datasheet for Johanson 160X18W224MV4E to view detailed technical specifications.
