100µF, 6.3V polarized aluminum electrolytic capacitor with 20% tolerance. Features a 2917 (7343 metric) surface mount chip package with tin, matte contact plating. Offers 15mΩ ESR, 4.1A ripple current, and 25.2µA leakage current. Operating temperature range from -55°C to 125°C, with a 2000-hour life rating. RoHS compliant.
Package2917
Voltage6.3V
Capacitance100uF
Voltage Rating6.3V
Quick Jump:
Technical Specifications
Kemet A700D107M006ATE015 technical specifications.
General
Capacitance
100uF
Case Code (Imperial)
2917
Case Code (Metric)
7343
Package/Case
2917
Construction
Flat
Contact Plating
Tin, Matte
Depth
4.3mm
Dielectric Material
Aluminium
Dissipation Factor
6%
ESR (Equivalent Series Resistance)
15mR
Height
2.8mm
Height - Seated (Max)
0.122inch
Lead Length
1.3mm
Leakage Current
25.2uA
Length
7.3mm
Life (Hours)
2000Hour
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount, PCB
Package Quantity
1
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
Ripple Current
4.1A
RoHS Compliant
Yes
Series
A700
Termination
SMD/SMT
Tolerance
20%
Voltage
6.3V
Voltage Rating
6.3V
DC Rated Voltage
6.3V
Width
0.169inch
Compliance
RoHS
Compliant
Datasheet
Kemet A700D107M006ATE015 Datasheet
Download the complete datasheet for Kemet A700D107M006ATE015 to view detailed technical specifications.
