Multilayer Ceramic Capacitor (MLCC) with 39pF capacitance and 5% tolerance, rated for 50V DC. Features C0G dielectric for stable performance across a -55°C to 125°C operating temperature range. Constructed with extreme low ESR and a 0402 (1005 metric) surface mount package. Packaged on tape and reel, this lead-free component is RoHS compliant.
Package0402
Voltage50V
Capacitance39pF
Voltage Rating50V
Quick Jump:
Technical Specifications
Kemet C0402C390J5GACTU technical specifications.
General
Capacitance
39pF
Case Code (Imperial)
0402
Case Code (Metric)
1005
Package/Case
0402
Construction
Flat
Depth
0.5mm
Dielectric
C0G
Dielectric Material
Ceramic
Dissipation Factor
0.1%
Height
0.5mm
Lead Free
Lead Free
Lead Pitch
0.3mm
Length
1mm
Material
Ceramic
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount, PCB
Package Quantity
10000
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
C0402C
Termination
SMD/SMT
Tolerance
5%
Voltage
50V
Voltage Rating
50V
DC Rated Voltage
50V
Width
0.5mm
Compliance
RoHS
Compliant
Datasheet
Kemet C0402C390J5GACTU Datasheet
Download the complete datasheet for Kemet C0402C390J5GACTU to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
