Multilayer Ceramic Capacitor (MLCC) with 220pF capacitance and 50V voltage rating. Features X7R dielectric material, 10% tolerance, and a 0805 surface mount package. Operates from -55°C to 125°C with a dissipation factor of 2.5%. Packaged in tape and reel for automated assembly.
Package0805
Voltage50V
Capacitance220pF
Voltage Rating50V
Quick Jump:
Technical Specifications
Kemet C0805C221K5RACTU technical specifications.
General
Capacitance
220pF
Case Code (Imperial)
0805
Case Code (Metric)
2012
Package/Case
0805
Construction
Flat
Depth
1.25mm
Dielectric
X7R
Dielectric Material
Ceramic
Dissipation Factor
2.5%
Height
0.78mm
Lead Free
Lead Free
Lead Pitch
0.75mm
Length
2mm
Material
Ceramic
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount, PCB
Package Quantity
1
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
C
Termination
SMD/SMT
Thickness
0.035inch
Tolerance
10%
Voltage
50V
Voltage Rating
50V
Voltage Rating (AC)
50V
DC Rated Voltage
50V
Width
0.049inch
Compliance
RoHS
Compliant
Datasheet
Kemet C0805C221K5RACTU Datasheet
Download the complete datasheet for Kemet C0805C221K5RACTU to view detailed technical specifications.
