Technical Specifications
Kemet R60PI2470AA30K technical specifications.
General
| Capacitance | 47nF |
| Package/Case | Radial |
| Depth | 5mm |
| Dielectric | PET |
| Dielectric Material | Polyester |
| Height | 11mm |
| Height - Seated (Max) | 0.472inch |
| Lead Diameter | 0.8mm |
| Lead Pitch | 15mm |
| Length | 18mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Package Quantity | 2000 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Series | R60 |
| Termination | Radial |
| Tolerance | 10% |
| Voltage Rating (AC) | 220V |
| DC Rated Voltage | 630V |
| Width | 0.197inch |
Compliance
| RoHS | Compliant |
Datasheet
Kemet R60PI2470AA30K Datasheet
Download the complete datasheet for Kemet R60PI2470AA30K to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
