Polarized tantalum capacitor, 330µF capacitance, 10V DC rated voltage, and 20% tolerance. Features a low ESR of 25mΩ, a ripple current rating of 4.6A, and a dissipation factor of 10%. Operates across a wide temperature range from -55°C to 105°C. Surface mountable in a 2917 (7343 metric) case code, constructed with solid polymer dielectric material. RoHS compliant and lead-free.
Package2917
Voltage10V
Capacitance330uF
Voltage Rating10V
Quick Jump:
Technical Specifications
Kemet T520X337M010ATE025 technical specifications.
General
Capacitance
330uF
Case Code (Imperial)
2917
Case Code (Metric)
7343
Package/Case
2917
Construction
Flat
Depth
4.3mm
Dielectric Material
Tantalum
Dissipation Factor
10%
ESR (Equivalent Series Resistance)
25mR
Features
General Purpose
Height
4mm
Lead Free
Lead Free
Leakage Current
330uA
Length
7.3mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Surface Mount, PCB
Package Quantity
500
Packaging
Tape and Reel
Polarity
Polar
Radiation Hardening
No
Reach SVHC Compliant
No
Ripple Current
4.6A
RoHS Compliant
Yes
Series
KO-CAP® T520
Termination
SMD/SMT
Tolerance
20%
Voltage
10V
Voltage Rating
10V
DC Rated Voltage
10V
Width
4.3mm
Compliance
RoHS
Compliant
Datasheet
Kemet T520X337M010ATE025 Datasheet
Download the complete datasheet for Kemet T520X337M010ATE025 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
