Solid tantalum capacitor, 6.8µF capacitance, 16V DC rated voltage, 10% tolerance. Features a B case (3528 metric, 1210 imperial) with dimensions of 3.5mm length, 2.8mm depth, and 2.1mm height. Surface mountable with SMD/SMT termination, operating from -55°C to 125°C. Includes 2.5 Ohm ESR and 1.1µA leakage current.
Package1210
Voltage16V
Capacitance6.8uF
Voltage Rating16V
Quick Jump:
Technical Specifications
Kyocera TAJB685K016RNJ technical specifications.
General
Capacitance
6.8uF
Case Code (Imperial)
1210
Case Code (Metric)
3528
Package/Case
1210
Construction
Flat
Depth
2.8mm
Dielectric Material
Tantalum
Dissipation Factor
6%
ESR (Equivalent Series Resistance)
2.5R
Features
General Purpose
Height
2.1mm
Height - Seated (Max)
0.083inch
Lead Free
Lead Free
Lead Pitch
1.4mm
Leakage Current
1.1uA
Length
3.5mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Polarity
Polar
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
TAJ
Termination
SMD/SMT
Tolerance
20%
Voltage
16V
Voltage Rating
16V
DC Rated Voltage
16V
Width
0.11inch
Compliance
RoHS
Compliant
Datasheet
Kyocera TAJB685K016RNJ Datasheet
Download the complete datasheet for Kyocera TAJB685K016RNJ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
