68µF, 4VDC Polymer Tantalum Capacitor with 20% tolerance. Features 70mΩ ESR and a maximum operating temperature of 125°C. Surface mountable in a 3528 (1210) case size, measuring 3.5mm x 2.8mm x 2.1mm. RoHS compliant with a dissipation factor of 6% and leakage current of 27.2µA.
Package1210
Capacitance68uF
Voltage Rating4V
MountingSurface Mount
Quick Jump:
Technical Specifications
Kyocera TCJB686M004R0070 technical specifications.
General
Capacitance
68uF
Case Code (Imperial)
1210
Case Code (Metric)
3528
Package/Case
1210
Construction
Flat
Depth
2.8mm
Dielectric Material
Tantalum
Dissipation Factor
6%
ESR (Equivalent Series Resistance)
70mR
Features
General Purpose
Height
2.1mm
Height - Seated (Max)
0.083inch
Lead Free
Lead Free
Leakage Current
27.2uA
Length
3.5mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
TCJ
Termination
SMD/SMT
Tolerance
20%
Voltage Rating
4V
DC Rated Voltage
4V
Width
2.8mm
Compliance
RoHS
Compliant
Datasheet
Kyocera TCJB686M004R0070 Datasheet
Download the complete datasheet for Kyocera TCJB686M004R0070 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
