Very Fast Acting Fuse Chip, 1A, 125V AC/DC, designed for surface mount applications. Features a ceramic and thermoplastic body with copper terminals, measuring 9.73mm x 5.03mm x 3.81mm. Operates across a wide temperature range from -55°C to 125°C with a low DC cold resistance of 153mR. This RoHS compliant component offers 125W power dissipation and holds UL, PSE approvals. Packaged in tape and reel for automated assembly.
PackageSMD/SMT
Storage5.03mm
Resistance153mR
Voltage Rating125V
Quick Jump:
Technical Specifications
Littelfuse 0154001.DR technical specifications.
General
Approvals
UL, PSE
Body Material
Ceramic, Thermoplastic
Package/Case
SMD/SMT
Current Rating
1A
DC Cold Resistance
153mR
Depth
5.03mm
Flammability Rating
UL94 V-0
Fuse Current
1A
Height
3.81mm
Lead Free
Lead Free
Length
9.73mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount, Holder
Package Quantity
1500
Packaging
Tape and Reel
Power Dissipation
125W
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Resistance
153mR
RoHS Compliant
Yes
Series
OMNI-BLOK® 154
Size
5.03mm
Terminal Material
Copper
Termination
SMD/SMT
Voltage Rating
125V
Voltage Rating (AC)
125V
DC Rated Voltage
125V
Width
5.03mm
Working Voltage
125V
Compliance
RoHS
Compliant
Datasheet
Littelfuse 0154001.DR Datasheet
Download the complete datasheet for Littelfuse 0154001.DR to view detailed technical specifications.
