Technical Specifications
Littelfuse 0KLK006.T technical specifications.
General
Package/Case
600
Current
6A
Current Rating
6A
Diameter
10.31mm
Lead Free
Lead Free
Length
38.1mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Holder, Surface Mount
Package Quantity
10
Packaging
Bulk
Radiation Hardening
No
Resistance
26.1mR
Series
KLK
Size
38.1mm
Termination
Clip
Type
Electrical
Voltage Rating
600V
Voltage Rating (AC)
600V
DC Rated Voltage
500V
Working Voltage
600V
Compliance
RoHS
Compliant
Datasheet
Littelfuse 0KLK006.T Datasheet
Download the complete datasheet for Littelfuse 0KLK006.T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
