Unidirectional transient voltage suppressor diode with 600W peak pulse power and 54A peak pulse current. Features a 6.4V reverse standoff voltage, 7.13V minimum breakdown voltage, and 11.3V clamping voltage. Designed for through-hole mounting in a DO-204AC (DO-15) plastic package with axial termination. Operates across a temperature range of -55°C to 175°C and offers a low leakage current of 500µA.
PackageDO-204AC
MountingThrough Hole
PolarityUnidirectional
Quick Jump:
Technical Specifications
Littelfuse P6KE7.5A-B technical specifications.
General
| Package/Case | DO-204AC |
| Clamping Voltage | 11.3V |
| Diameter | 3.6mm |
| Diode Type | ZENER |
| Lead Free | Lead Free |
| Leakage Current | 500uA |
| Length | 7.6mm |
| Min Breakdown Voltage | 7.13V |
| Max Operating Temperature | 175°C |
| Min Operating Temperature | -55°C |
| Max Surge Current | 53A |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 6.4V |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Peak Pulse Current | 54A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Reverse Breakdown Voltage | 7.13V |
| Reverse Standoff Voltage | 6.4V |
| RoHS Compliant | Yes |
| Series | P6KE |
| Termination | Axial |
| DC Rated Voltage | 7.5V |
Compliance
| RoHS | Compliant |
Datasheet
Littelfuse P6KE7.5A-B Datasheet
Download the complete datasheet for Littelfuse P6KE7.5A-B to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
