Unidirectional Transient Voltage Suppressor (TVS) diode, 400W peak pulse power, designed for surface mount applications in a DO-214AC package. Features an 8.5V reverse standoff voltage and a maximum clamping voltage of 14.4V. Offers a maximum breakdown voltage of 10.4V and a leakage current of 20µA. Operates across a temperature range of -65°C to 150°C, with a maximum power dissipation of 3.3W. This silicon component is RoHS compliant and Halogen Free.
PackageDO-214AC
MountingSurface Mount
PolarityUnidirectional
Power400W
Quick Jump:
Technical Specifications
Littelfuse SMAJ8.5A technical specifications.
General
Package/Case
DO-214AC
Clamping Voltage
137V
Clamping Voltage-Max
14.4V
Diode Type
ZENER
Direction
Unidirectional
Height
2.29mm
Lead Free
Lead Free
Leakage Current
20uA
Length
5.28mm
Max Breakdown Voltage
10.4V
Min Breakdown Voltage
94.4V
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Power Dissipation
3.3W
Max Surge Current
2.9A
Mount
Surface Mount
Number of Channels
1
Number of Elements
1
Number of Unidirectional Channels
1
Operating Supply Voltage
85V
Package Quantity
5000
Packaging
Tape and Reel
Peak Pulse Current
27.8A
Peak Pulse Power
400W
Polarity
Unidirectional
Power Dissipation
400W
Power Line Protection
No
Reach SVHC Compliant
No
Reverse Breakdown Voltage
9.44V
Reverse Standoff Voltage
8.5V
RoHS Compliant
Yes
Series
SMAJ
Termination
SMD/SMT
DC Rated Voltage
8.5V
Width
2.79mm
Compliance
RoHS
Compliant
Datasheet
Littelfuse SMAJ8.5A Datasheet
Download the complete datasheet for Littelfuse SMAJ8.5A to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
