Technical Specifications
MCC US1A-TP technical specifications.
General
Average Rectified Current
1A
Package/Case
DO-214AC
Forward Current
1A
Height
2.24mm
Lead Free
Lead Free
Length
4.6mm
Max Forward Surge Current (Ifsm)
30A
Max Operating Temperature
175°C
Min Operating Temperature
-65°C
Max Repetitive Reverse Voltage (Vrrm)
50V
Max Reverse Current
10uA
Max Reverse Voltage (DC)
50V
Max Surge Current
30A
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Peak Non-Repetitive Surge Current
30A
Reach SVHC Compliant
Unknown
Reverse Recovery Time
50ns
Reverse Recovery Time-Max
50ns
Reverse Voltage
50V
RoHS Compliant
Yes
Width
2.92mm
Compliance
RoHS
Compliant
Datasheet
MCC US1A-TP Datasheet
Download the complete datasheet for MCC US1A-TP to view detailed technical specifications.
