Technical Specifications
Mean Well GS05E-USB technical specifications.
General
Current - Output 1
1A
Efficiency
71%
Height
0.8inch
Length
1.7inch
Max Input Current
150mA
Max Operating Temperature
50°C
Min Operating Temperature
-20°C
Max Output Power
5W
Number of Outputs
1
Output Current
1A
Series
GS05E
Voltage - Output 1
5V
Weight
2.116438oz
Width
1.2inch
Compliance
RoHS
Compliant
Datasheet
Mean Well GS05E-USB Datasheet
Download the complete datasheet for Mean Well GS05E-USB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
