Package100
MountingPanel, Desktop
Power25.2W
Quick Jump:
Technical Specifications
Mean Well LPF-25D-12 technical specifications.
General
Approvals
UL, CSA, TUV, EN
Package/Case
100
Current - Output 1
2.1A
Depth
40mm
Efficiency
84%
Height
1.3inch
Lead Free
Lead Free
Length
5.8inch
Max Input Current
400mA
Max Operating Temperature
70°C
Min Operating Temperature
-40°C
Max Output Power
25.2W
Mount
Panel, Desktop
Number of Outputs
1
Output Current
2.1A
Output Power
25.2W
Output Voltage
12V
RoHS Compliant
Yes
Series
LPF-25D
Voltage - Output 1
12V
Weight
12.698626oz
Width
1.6inch
Compliance
RoHS
Compliant
Datasheet
Mean Well LPF-25D-12 Datasheet
Download the complete datasheet for Mean Well LPF-25D-12 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
