Microchip
93LC66AT-I/MC
512 X 8 MICROWIRE BUS SERIAL EEPROM, PDSO8, 2 X 3 MM, 0.90 MM HEIGHT, ROHS COMPLIANT, PLASTIC, DFN-8
Frequency2MHz
PackageDFN
Current2mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip 93LC66AT-I/MC technical specifications.
General
Access Time-Max
250ns
Package/Case
DFN
Contact Plating
Tin, Matte
Density
4Kb
Frequency
2MHz
Interface
3-WIRE, Serial
Lead Free
Lead Free
Max Frequency
1MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Memory Size
4Kb
Memory Type
EEPROM,
Min Supply Voltage
2.5V
Mount
Surface Mount
Operating Supply Voltage
5V
Organization
512X8
Package Quantity
3300
Packaging
Tape and Reel
RoHS Compliant
Yes
Supply Current
2mA
Write Protection
YES
Compliance
RoHS
Compliant
Datasheet
Microchip 93LC66AT-I/MC Datasheet
Download the complete datasheet for Microchip 93LC66AT-I/MC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
