The AT91SAM7X256-CU-999 is a surface mount microcontroller with a 32-bit ARM core operating at up to 55MHz. It features 256KB of FLASH memory and 64KB of RAM. The device supports a range of interfaces including CAN, I2S, I2C, SPI, USB, Ethernet, UART, and USART. It also includes peripherals such as brown-out detect/reset, power-on reset, pulse-width modulation, and a watchdog timer. The microcontroller is packaged in a TFBGA package and is rated for operation over the -40°C to 85°C temperature range.
Frequency55MHz
PackageTFBGA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip AT91SAM7X256-CU-999 technical specifications.
General
| Package/Case | TFBGA |
| Core Architecture | ARM |
| Data Bus Width | 32b |
| Interface | CAN, I2S, I2C, SPI, USB, Ethernet, UART, USART |
| Max Frequency | 55MHz |
| Max Operating Temperature | 85°C |
| Memory Size | 256KB |
| Memory Type | FLASH, |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of I/Os | 62 |
| Operating Supply Voltage | 3.3V |
| Oscillator Type | Internal |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT, DMA |
| RAM Size | 64KB |
| Series | SAM7X |
Compliance
| RoHS | Not Compliant |
Datasheet
Microchip AT91SAM7X256-CU-999 Datasheet
Download the complete datasheet for Microchip AT91SAM7X256-CU-999 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
