32-bit ARM microcontroller featuring 256KB FLASH memory and 64KB RAM. Operates at 55MHz with 62 I/Os, supporting I2C, SPI, USB, Ethernet, UART, USART, and CAN interfaces. Includes internal oscillator, brown-out detect/reset, POR, PWM, WDT, and DMA peripherals. Packaged in LQFP, this lead-free component operates from 1.65V to 1.95V, with a temperature range of -40°C to 85°C.
Frequency55MHz
PackageLQFP
Quick Jump:
Technical Specifications
Microchip AT91SAM7X256C-AU technical specifications.
General
Package/Case
LQFP
Core Architecture
ARM
Frequency
55MHz
Interface
I2C, SPI, USB, Ethernet, UART, USART, CAN
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
1.95V
Memory Size
256KB
Memory Type
FLASH,
Min Supply Voltage
1.65V
Number of I/Os
62
Oscillator Type
Internal
Packaging
Tray
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT, DMA
RAM Size
64KB
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
SAM7X
Compliance
RoHS
Compliant
Datasheet
Microchip AT91SAM7X256C-AU Datasheet
Download the complete datasheet for Microchip AT91SAM7X256C-AU to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
