Frequency125MHz
PackagePDIP
Current55mA
MountingThrough Hole
Quick Jump:
Technical Specifications
Microchip ATF20V8B-7PC technical specifications.
General
Package/Case
PDIP
Max Frequency
125MHz
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
5.25V
Min Supply Voltage
4.75V
Mount
Through Hole
Number of Macrocells
8
Package Quantity
15
Packaging
Rail/Tube
RoHS Compliant
No
Series
20V8
Supply Current
55mA
Compliance
RoHS
Not Compliant
Datasheet
Microchip ATF20V8B-7PC Datasheet
Download the complete datasheet for Microchip ATF20V8B-7PC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
