PackageTO-220-5
MountingThrough Hole
Quick Jump:
Technical Specifications
Microchip LM2575WT technical specifications.
General
Package/Case
TO-220-5
Lead Free
Lead Free
Max Input Voltage
40V
Min Input Voltage
4V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
1A
Max Output Voltage
37V
Min Output Voltage
1.23V
Mount
Through Hole
Number of Outputs
1
Output Configuration
Positive
Output Current
1A
Output Type
Adjustable
Package Quantity
50
Packaging
Rail/Tube
RoHS Compliant
Yes
Synchronous Rectifier
No
Compliance
RoHS
Compliant
Datasheet
Microchip LM2575WT Datasheet
Download the complete datasheet for Microchip LM2575WT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
