This CAN controller IC offers a 1Mbps data rate and operates with a 25MHz frequency. Featuring a 14-pin SOIC surface mount package, it provides 2 receive and 3 transmit buffers, along with 8 I/Os. The device supports a supply voltage range of 2.7V to 5.5V and a maximum supply current of 20mA, with an operating temperature range of -40°C to 85°C. It includes a single CAN transceiver and push-pull output type, packaged in a rail/tube for 57 units.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip MCP25020-I/SL datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Microchip MCP25020-I/SL technical specifications.
| Package/Case | SOIC |
| Data Rate | 1Mbps |
| Frequency | 25MHz |
| Height | 1.5mm |
| Interface | CAN, Serial |
| Lead Free | Lead Free |
| Length | 8.65mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Current | 20mA |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Number of Functions | 1 |
| Number of I/Os | 8 |
| Number of Receive Buffers | 2 |
| Number of Transceivers | 1 |
| Number of Transmit Buffers | 3 |
| Output Type | PUSH-PULL |
| Package Quantity | 57 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 20mA |
| Supply Voltage-Nom | 5.5V |
| Width | 3.9mm |
| RoHS | Compliant |
