8-bit microcontroller featuring 7KB OTP memory and 176B RAM. Operates at up to 20MHz with an 8-bit data bus width and supports RS-232 interface. Includes 33 programmable I/O pins and 8 timers/counters, with peripherals like Brown-out Detect/Reset, POR, and WDT. Designed for surface mount installation in a TQFP package, this lead-free component functions across a -40°C to 125°C temperature range.
Frequency20MHz
PackageTQFP
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip PIC16C662T-20E/PT technical specifications.
General
Access Time
20us
Package/Case
TQFP
Core Architecture
PIC
Data Bus Width
8b
Interface
RS-232
Lead Free
Lead Free
Max Frequency
20MHz
Max Operating Temperature
125°C
Max Power Dissipation
1W
Max Supply Voltage
6V
Memory Size
7KB
Memory Type
EPROM, , OTP
Min Operating Temperature
-40°C
Min Supply Voltage
4V
Mount
Surface Mount
Number of Programmable I/O
33
Number of Timers/Counters
8
Oscillator Type
External
Package Quantity
1200
Packaging
Tape and Reel
Peripherals
Brown-out Detect/Reset, POR, WDT
Radiation Hardening
No
RAM Size
176B
Series
PIC® 16C
Watchdog Timer
Yes
Compliance
RoHS
Compliant
Datasheet
Microchip PIC16C662T-20E/PT Datasheet
Download the complete datasheet for Microchip PIC16C662T-20E/PT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
