8-bit RISC microcontroller featuring 1.5KB FLASH memory and 72B RAM. Operates at up to 20MHz with an internal oscillator and supports USB interface. Offers 11 programmable I/O pins, one timer/counter, and includes POR and WDT peripherals. Encased in a lead-free, RoHS compliant QFN package, this surface-mount component functions within a -40°C to 85°C temperature range and a 2V to 5.5V supply voltage.
Frequency20MHz
PackageQFN
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip PIC16F505-I/MG technical specifications.
General
Package/Case
QFN
Core Architecture
PIC
Data Bus Width
8b
Frequency
20MHz
Interface
USB
Lead Free
Lead Free
Max Frequency
20MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
800mW
Max Supply Voltage
5.5V
Memory Size
1.5KB
Memory Type
FLASH,
Min Supply Voltage
2V
Mount
Surface Mount
Number of I/Os
11
Number of Programmable I/O
11
Number of Timers/Counters
1
Oscillator Type
Internal
Packaging
Rail/Tube
Peripherals
POR, WDT
Radiation Hardening
No
RAM Size
72B
RoHS Compliant
Yes
Series
PIC® 16F
Watchdog Timer
Yes
Compliance
RoHS
Compliant
Datasheet
Microchip PIC16F505-I/MG Datasheet
Download the complete datasheet for Microchip PIC16F505-I/MG to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
