Current30mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip SST39VF800A-70-4I-MAQE-T technical specifications.
General
Access Time-Max
70ns
Address Bus Width
19b
Data Bus Width
16b
Density
8Mb
Interface
Parallel
Max Operating Temperature
85°C
Max Supply Voltage
3.6V
Memory Size
8Mb
Memory Type
NOR, , FLASH
Min Operating Temperature
-40°C
Min Supply Voltage
2.7V
Mount
Surface Mount
Number of Words
512000
Operating Supply Voltage
3.3V
Package Quantity
2500
Packaging
Tape and Reel
Radiation Hardening
No
RoHS Compliant
Yes
Series
SST39 MPF™
Supply Current
30mA
Sync/Async
Asynchronous
Word Size
16b
Compliance
RoHS
Compliant
Datasheet
Microchip SST39VF800A-70-4I-MAQE-T Datasheet
Download the complete datasheet for Microchip SST39VF800A-70-4I-MAQE-T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
