General Purpose Analog Front End (AFE) IC featuring a single 17-bit Analog-to-Digital Converter (ADC). This surface-mount component operates with a 5V supply voltage, ranging from 4.5V to 7.5V, and consumes 1mA of current. It utilizes a 3-wire serial interface for data transfer and is housed in a 16-pin SOIC package with dimensions of 10.3mm x 7.49mm x 2.31mm. The device supports a temperature range of 0°C to 70°C and is RoHS compliant.
PackageSOIC
Current1mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip TC500ACOE technical specifications.
General
Package/Case
SOIC
Height
2.31mm
Interface
Serial, 3-WIRE
Lead Free
Lead Free
Length
10.3mm
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Power Dissipation
10mW
Max Supply Voltage
7.5V
Min Supply Voltage
4.5V
Mount
Surface Mount
Number of A/D Converters
1
Number of Bits
17
Number of Channels
1
Operating Supply Current
1mA
Operating Supply Voltage
5V
Output Voltage
900mV
Package Quantity
47
Packaging
Rail/Tube
Reach SVHC Compliant
No
Resolution
17b
RoHS Compliant
Yes
Sampling Rate
10S/s
Supply Current
1mA
Width
7.49mm
Compliance
RoHS
Compliant
Datasheet
Microchip TC500ACOE Datasheet
Download the complete datasheet for Microchip TC500ACOE to view detailed technical specifications.
