Surface mount voltage detector IC with a 2.1V threshold, featuring active low reset output. Monitors a single voltage with undervoltage detection at 2.06V and overvoltage detection at 2.14V. Operates from a 700mV to 10V supply, with a maximum power dissipation of 500mW. Designed for lead-free, SOT-89-3 packaging, suitable for temperatures from -40°C to 85°C.
PackageSOT-89-3
MountingSurface Mount
Power500mW
Quick Jump:
Technical Specifications
Microchip TC54VC2102EMB713 technical specifications.
General
Package/Case
SOT-89-3
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
500mW
Max Reset Threshold Voltage
2.14V
Min Reset Threshold Voltage
2.06V
Max Supply Voltage
10V
Min Supply Voltage
700mV
Mount
Surface Mount
Number of Voltages Monitored
1
Operating Supply Current
3.6uA
Output
TOTEM-POLE
Overvoltage Threshold
2.14V
Package Quantity
1000
Packaging
Tape and Reel
Power Dissipation
500mW
Quiescent Current
1.1uA
Reset
Active Low
RoHS Compliant
Yes
Threshold Voltage
2.1V
Type
Simple Reset/Power-On Reset, Voltage Detector
Undervoltage Threshold
2.06V
Watchdog Timer
No
Compliance
RoHS
Compliant
Datasheet
Microchip TC54VC2102EMB713 Datasheet
Download the complete datasheet for Microchip TC54VC2102EMB713 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
