Technical Specifications
Micron N25Q512A13GF840E technical specifications.
General
| Address Bus Width | 1b |
| Density | 512Mb |
| Frequency | 108MHz |
| Interface | SPI, Serial |
| Max Operating Temperature | 85°C |
| Memory Size | 512Mb |
| Memory Type | Non-Volatile, , FLASH, NOR |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Operating Supply Voltage | 3V |
| Packaging | Tray |
| RoHS Compliant | No |
| Supply Current | 20mA |
| Sync/Async | Synchronous |
| Voltage | 2.7V |
Compliance
| RoHS | Not Compliant |
Datasheet
Micron N25Q512A13GF840E Datasheet
Download the complete datasheet for Micron N25Q512A13GF840E to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
