Single layer ceramic capacitor with 2.2nF capacitance and 20% tolerance. Features a 250VAC voltage rating, 125°C maximum operating temperature, and through-hole mounting with radial leads. Constructed from ceramic material, this component is RoHS compliant and supplied in an ammo pack. Dimensions include 10mm length, 7mm depth, and 7.5mm lead pitch.
PackageRadial
Voltage250V
Capacitance2.2nF
Voltage Rating250V
Quick Jump:
Technical Specifications
Murata DE2E3KH222MN3A technical specifications.
General
Capacitance
2.2nF
Package/Case
Radial
Construction
RADIAL
Depth
7mm
Height - Seated (Max)
0.512inch
Lead Diameter
0.6mm
Lead Free
Lead Free
Lead Pitch
7.5mm
Lead/Base Style
Formed Leads
Length
10mm
Material
Ceramic
Max Operating Temperature
125°C
Min Operating Temperature
-25°C
Mount
Through Hole
Package Quantity
1
Packaging
Ammo Pack
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
KH
Termination
Radial
Tolerance
20%
Voltage
250V
Voltage Rating
250V
Voltage Rating (AC)
300V
Compliance
RoHS
Compliant
Datasheet
Murata DE2E3KH222MN3A Datasheet
Download the complete datasheet for Murata DE2E3KH222MN3A to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
