The Nichicon UBT1H220MPD8 is a 22uF radial aluminum electrolytic capacitor with a 50V voltage rating and 20% tolerance. It has a maximum operating temperature of 125°C and a minimum operating temperature of -40°C. The capacitor is RoHS compliant and has a leakage current of 4uA. It is available in a radial package with a diameter of 8mm and a height of 11.5mm, and is mounted through a hole. The capacitor has an ESR of 500mR and an impedance of 500mR.
PackageRadial
Voltage50V
Capacitance22uF
Voltage Rating50V
Quick Jump:
Technical Specifications
Nichicon UBT1H220MPD8 technical specifications.
General
| Capacitance | 22uF |
| Package/Case | Radial |
| Construction | RADIAL |
| Diameter | 8mm |
| ESR (Equivalent Series Resistance) | 500mR |
| Height | 11.5mm |
| Impedance | 500mR |
| Lead Diameter | 0.6mm |
| Lead Pitch | 3.5mm |
| Leakage Current | 4uA |
| Life (Hours) | 2000Hour |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Series | UBT |
| Tolerance | 20% |
| Voltage | 50V |
| Voltage Rating | 50V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon UBT1H220MPD8 Datasheet
Download the complete datasheet for Nichicon UBT1H220MPD8 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
