NICHICON

UBX1H221MPL

Datasheet

220uF 50V Aluminum Electrolytic Capacitor, Radial, 150°C, 640mA

Nichicon

UBX1H221MPL

Name: UBX1H221MPL Nichicon
Brand: Nichicon
SKU: UBX1H221MPL

220uF 50V Aluminum Electrolytic Capacitor, Radial, 150°C, 640mA

Standard aluminum electrolytic capacitor, 220µF capacitance, 50V DC rated voltage, and 20% tolerance. Features a radial package with a 5mm lead pitch, 10mm diameter, and 20mm height. Operates across a -55°C to 150°C temperature range with a 1000-hour life rating at 150°C. Offers 640mA ripple current and 330µA leakage current. Through-hole mount, lead-free, and RoHS compliant.

PackageRadial

Voltage50V

Capacitance220uF

Voltage Rating50V

Quick Jump:

Technical Specifications

Nichicon UBX1H221MPL technical specifications.

General

Capacitance	220uF
Package/Case	Radial
Construction	RADIAL
Diameter	10mm
Height	20mm
Height - Seated (Max)	0.846inch
Lead Diameter	0.6mm
Lead Free	Lead Free
Lead Pitch	5mm
Leakage Current	330uA
Length	20mm
Life (Hours)	1000Hour
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Mount	Through Hole
Package Quantity	200
Packaging	Bulk
Radiation Hardening	No
Ripple Current	640mA
RoHS Compliant	Yes
Series	UBX
Termination	Radial
Tolerance	20%
Voltage	50V
Voltage Rating	50V
DC Rated Voltage	50V
