Aluminum electrolytic capacitor with 47µF capacitance and 400V DC rated voltage. Features 20% tolerance, 1.18A ripple current, and a maximum operating temperature of 105°C. This radial component has a 7.5mm lead pitch, 16mm diameter, and 25mm height, suitable for through-hole mounting. Rated for 10,000 hours of life, it operates from -40°C to 105°C and is RoHS compliant.
PackageRadial
Voltage400V
Capacitance47uF
Voltage Rating400V
Quick Jump:
Technical Specifications
Nichicon UCS2G470MHD technical specifications.
General
Capacitance
47uF
Package/Case
Radial
Construction
RADIAL
Diameter
16mm
Dissipation Factor
0.24%
Height
25mm
Height - Seated (Max)
1.043inch
Lead Diameter
0.8mm
Lead Pitch
7.5mm
Length
25mm
Life (Hours)
10000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
50
Packaging
Bulk
Polarity
Polar
Radiation Hardening
No
Ripple Current
1.18A
Ripple Current (AC)
1.18A
RoHS Compliant
Yes
Series
CS
Termination
Radial
Tolerance
20%
Voltage
400V
Voltage Rating
400V
DC Rated Voltage
400V
Compliance
RoHS
Compliant
Datasheet
Nichicon UCS2G470MHD Datasheet
Download the complete datasheet for Nichicon UCS2G470MHD to view detailed technical specifications.
