Nichicon
ULV2E8R2MNL1GS
Cap Aluminum Lytic 8.2uF 250V 20% (8 X 10mm) SMD 35mA 10000h 105°C Automotive T/R
PackageSMD/SMT
Voltage250V
Capacitance8.2uF
Voltage Rating250V
Quick Jump:
Technical Specifications
Nichicon ULV2E8R2MNL1GS technical specifications.
General
Capacitance
8.2uF
Package/Case
SMD/SMT
Diameter
10mm
Height
13.5mm
Lead Pitch
4.5mm
Leakage Current
182mA
Length
10mm
Life (Hours)
10000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Package Quantity
500
Packaging
Tape and Reel
Ripple Current
35mA
RoHS Compliant
Yes
Series
ULV
Termination
SMD/SMT
Tolerance
20%
Voltage
250V
Voltage Rating
250V
DC Rated Voltage
250V
Compliance
RoHS
Compliant
Datasheet
Nichicon ULV2E8R2MNL1GS Datasheet
Download the complete datasheet for Nichicon ULV2E8R2MNL1GS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
