PackageRadial
Capacitance12uF
Voltage Rating50V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon UPM1H120MDD1TD technical specifications.
General
Capacitance
12uF
Package/Case
Radial
Diameter
5mm
Height - Seated (Max)
0.492inch
Impedance
1.2R
Lead Pitch
0.079inch
Length
11mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole
Package Quantity
1
Packaging
Tape and Reel
Ripple Current
62mA
RoHS Compliant
Yes
Series
PM
Termination
Radial
Tolerance
20%
Voltage Rating
50V
DC Rated Voltage
50V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPM1H120MDD1TD Datasheet
Download the complete datasheet for Nichicon UPM1H120MDD1TD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
