Aluminum electrolytic capacitor with 6.8mF capacitance and 10V DC rated voltage. Features 20% tolerance, 33mR impedance, and 2.35A ripple current capability. Designed for general purpose applications with a 3000-hour life at 105°C maximum operating temperature. Radial package with 7.5mm lead pitch, 16mm diameter, and 31.5mm height. Through-hole mounting.
PackageRadial
Voltage10V
Capacitance6.8mF
Voltage Rating10V
Quick Jump:
Technical Specifications
Nichicon UPS1A682MHD technical specifications.
General
Capacitance
6.8mF
Package/Case
Radial
Construction
RADIAL
Diameter
16mm
Features
General Purpose
Height
31.5mm
Height - Seated (Max)
1.319inch
Impedance
33mR
Lead Diameter
0.8mm
Lead Pitch
7.5mm
Leakage Current
2.04mA
Length
31.5mm
Life (Hours)
3000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole
Package Quantity
50
Packaging
Bulk
Radiation Hardening
No
Ripple Current
2.35A
RoHS Compliant
Yes
Series
PS
Termination
Radial
Tolerance
20%
Voltage
10V
Voltage Rating
10V
DC Rated Voltage
10V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPS1A682MHD Datasheet
Download the complete datasheet for Nichicon UPS1A682MHD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
