Nichicon
UPS1J681MHD
Cap Aluminum Lytic 680uF 63V 20% (16 X 25mm) Radial 7.5mm 1300mA 3000h 105°C Bulk
PackageRadial
Capacitance680uF
Voltage Rating63V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon UPS1J681MHD technical specifications.
General
Capacitance
680uF
Package/Case
Radial
Diameter
16mm
Height
25mm
Impedance
58mR
Lead Pitch
7.5mm
Leakage Current
1.2852mA
Length
25mm
Life (Hours)
3000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole
Package Quantity
50
Packaging
Bulk
Radiation Hardening
No
Ripple Current
1.3A
RoHS Compliant
Yes
Series
UPS
Termination
Radial
Tolerance
20%
Voltage Rating
63V
DC Rated Voltage
63V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPS1J681MHD Datasheet
Download the complete datasheet for Nichicon UPS1J681MHD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
