PackageRadial
Capacitance1mF
Voltage Rating16V
MountingSurface Mount
Quick Jump:
Technical Specifications
Nichicon UUJ1C102MNQ6MS technical specifications.
General
Capacitance
1mF
Package/Case
Radial
Diameter
12.5mm
Height - Seated (Max)
0.689inch
Leakage Current
4uA
Length
21mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Polarity
Polar
Ripple Current
630mA
Ripple Current (AC)
630mA
RoHS Compliant
Yes
Series
UJ
Termination
SMD/SMT
Tolerance
20%
Voltage Rating
16V
DC Rated Voltage
16V
Compliance
RoHS
Compliant
Datasheet
Nichicon UUJ1C102MNQ6MS Datasheet
Download the complete datasheet for Nichicon UUJ1C102MNQ6MS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
