PackageRadial
Capacitance220uF
Voltage Rating25V
MountingSurface Mount
Quick Jump:
Technical Specifications
Nichicon UUR1E221MNL6GS technical specifications.
General
Capacitance
220uF
Package/Case
Radial
Construction
Cylindrical
Diameter
8mm
Dissipation Factor
0.16%
Features
General Purpose
Height
10mm
Height - Seated (Max)
0.413inch
Length
10mm
Life (Hours)
2000Hour
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Package Quantity
500
Packaging
Tape and Reel
Radiation Hardening
No
Ripple Current
232mA
RoHS Compliant
Yes
Series
UR
Termination
SMD/SMT
Tolerance
20%
Voltage Rating
25V
DC Rated Voltage
25V
Compliance
RoHS
Compliant
Datasheet
Nichicon UUR1E221MNL6GS Datasheet
Download the complete datasheet for Nichicon UUR1E221MNL6GS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
